MutSeqR: General Visualization
Annette E. Dodge
Environmental Health Science and Research Bureau, Health Canada, Ottawa, ON, Canada.Matthew J. Meier
matthew.meier@hc-sc.gc.ca Source:vignettes/articles/General_Visualizations.Rmd
General_Visualizations.RmdLoad MutSeqR and Example Data
The example data consists of 24 mouse bone marrow DNA samples imported using import_mut_data() and filtered with filter_mut. Data was sequenced on the TS Mouse Mutagenesis Panel. Example data is retrieved from MutSeqRData, an ExperimentHub data package.
library(ExperimentHub)
# load the index
eh <- ExperimentHub()Bubble Plots
plot_bubbles is used to visually represent the
distribution and density of mutations that are observed in multiple
reads (multiplets). Each mutation in a given group is represented by a
bubble whose size is scaled on either the alt_depth or the
vaf. Thus mutations that occur in a large number of reads
are represented by a large bubble. These plots make it easy to determine
if MFmax is driven by a few highly expanded mutations versus serveral
moderately expanded mutations.
Plots can be facetted by user-defined groups, and bubbles can be coloured by any variable of interest to help discern patterns in mutation recurrence.
Example 1. Plot mutations per dose group, bubbles coloured by base-6 subtype
# load example data:
example_data <- eh[["EH9861"]]
plot <- plot_bubbles(
mutation_data = example_data,
size_by = "alt_depth",
facet_col = "dose_group",
color_by = "normalized_subtype"
)
plot
Multiplet mutations plotted per Dose. Each circle represents a mutation, coloured by mutation subtype. The size of the circle is scaled by the mutation’s alternative depth.
Radar Plots
plot_radar() is used to visualize mutation frequencies
across specified groups as a radar/spider plot. Plots may also be
facetted across a second group.
Example 2. Plot the mutation frequency for each of the 20 genomic targets of the TwinStrand Mutagenesis Panel. Facet panels by dose group.
First we will calculate the average MFmin for each genomic target across dose groups. We will also define the order in which the genomic targets should appear on our plot. We will arrange genomic targets based on their genic context so that we can visualize differences in mutation frequency driven be genic context.
mf <- calculate_mf(
mutation_data = example_data,
cols_to_group = c("sample", "label"),
retain_metadata_cols = c("dose_group", "genic_context")
)
label_order <- mf %>%
dplyr::arrange(genic_context) %>%
dplyr::pull(label) %>%
unique()
avg <- mf %>%
dplyr::group_by(dose_group, label) %>%
dplyr::summarise(mean_mf = mean(mf_min))
avg$label <- factor(avg$label, levels = label_order)
avg$dose_group <- factor(avg$dose_group,
levels = c("Control", "Low", "Medium", "High")
)
plot <- plot_radar(
mf_data = avg,
response_col = "mean_mf",
label_col = "label",
facet_col = "dose_group",
indiv_y = FALSE
)
Average Minimum Mutation Frequency (mutation/bp) per genomic target. Plots are facetted by dose group.
plot## NULLThis plot shows us that average mutation frequency increases with dose. Second, intergenic targets (targets on the left of the plot) show higher mutation frequencies compared to genic targets (targets on the right side of the plot).
Lollipop Plots
plot_lollipop()is used to visualize recurrent mutations.
Recurrent mutations may be analysed across the entire data sets or
across user-specified variable(s) (ex. sample, contig, dose). Mutations
may also be analysed at the various subtype resolutions. Mutations i a
group that occur above a specified recurrence threshold are plotted by
genomic position. If specified, mutations are colored by their mutation
subtype. For each level in the specified group, a lollipop plot will be
generated and stored in a list.
Example 3. We will visualize mutations that occur a minimum of 2 times in a group Mutations will be grouped by genomic target (label) and by dose group Recurring mutations will be resolved at the base_6 level
plot_list <- plot_lollipop(
mutation_data = example_data,
min_recurrence = 2,
group_col = c("label", "dose_group"),
subtype_resolution = "base_6"
)
plot_list[50]## $`chr2 | High`
Recurrent mutations in target chr 2 found in the High dose group plotted by genomic position and coloured by normalized subtype. Plots are separated by genomic target.
